1.功能简介
1. Function Introduction

1.1功能概述
1.1 Function Overview

GC-1502模块是集成2路脉冲计数器。该计数器可用于实时采集脉冲信号，并将采集到的数值通过内部总线发送给GCAN-PLC-3/4/5系列PLC主控模块或GCAN-8X00系列耦合器。该模块可与其他任何GC系列IO模块搭配使用，实现工业自动化或分布式控制系统中模拟量数据的采集与处理。
The GC-1502 module integrates two pulse counters. This counter can be used to collect pulse signals in real-time and send the collected values to the GCAN-PLC-3/4/5 series PLC main control module or GCAN-8X00 series coupler through an internal bus. This module can be used in conjunction with any other GC series IO module to achieve the acquisition and processing of analog data in industrial automation or distributed control systems.

1.2性能特点
1.2 Performance Characteristics

●输入通道数为2个；
●The number of input channels is 2;
●输入脉冲电压为5~24V；
●The input pulse voltage is 5~24V;
●输入电流最大值为3mA；
●The maximum input current is 3mA;
●输入脉冲信号最大频率200kHz；
●The maximum frequency of the input pulse signal is 200kHz;
●电气隔离为500Vrms（GC-bus信号电压）；
●Electrical isolation is 500Vrms (GC bus signal voltage);
●32位计数器；
●32-bit counter;
●组态无地址设置，通过总线耦合器或控制器配置；
●Configuration without address setting, configured through bus coupler or controller;
●工作温度范围：-40℃~+85℃；
●Working temperature range: -40 ℃~+85 ℃;
●尺寸：长100mm*宽69mm*高12mm。
●Size: Length 100mm * Width 69mm * Height 12mm.

1.3典型应用
1.3 Typical Applications

●分布式采集系统采集数字量；
●Distributed data collection system collects digital data;
●工业现场采集开关量。
●Collect switch values on industrial sites.

GC-1502设备使用手册链接
GC-1502 Equipment User Manual Link

www.gcgd.net/filedownload/2977825
